Flanged Gate Valve: Durable, Reliable, and Built for Performance
Are you in need of a flanged gate valve that will give you the much needed reliability and performance? RUF Supply is a leader in delivering precision engineered flanged gate valves for industrial, commercial and residential applications. Our valves are highly resistant and very durable which allows to operate them in conditions that are extremely harsh.
Whether it is a new valve you are looking for, or a change over from your existing one, or looking to compare the dimensions or even enquiring a cheaper deal, this buyer’s guide will offer you all you would require for making the right choice. Find out more why RUF Supply is the preferred choice of buyers globally.
Flanged Gate Valve Specification
| Parameter | Specification |
|---|---|
| Valve Type | Flanged Gate Valve |
| Material | Alloy 20 / Duplex Steel / Carbon Steel / Stainless Steel |
| Size Range | 2″ – 48″ (50mm – 1200mm) |
| Pressure Rating | PN10, PN16, PN25, ANSI 150, ANSI 300 |
| Flange Standard | ANSI B16.5, DIN 2501, ISO 7005 |
| Face-to-Face Standard | ANSI B16.10, API 6D, ISO 5752 |
| End Connection Type | Flanged |
| Temperature Range | -29°C to 425°C (-20°F to 800°F) |
| Operation | Handwheel, Gear Operated, Pneumatic, Electric |
| Stem Type | Rising Stem / Non-Rising Stem |
| Sealing Type | Metal Seated / Soft Seated |
| Body Design | Bolted Bonnet / Pressure Seal |
| Testing Standard | API 598, ISO 5208 |
| Applications | Water, Oil, Gas, Steam, Chemical Services |
| Coating | Fusion Bonded Epoxy (FBE), Painted |
| Compliance | API 600, BS EN 13709, ASME B16.34 |
Different Types of Flanged Gate Valve
Flanged gate valves contain a pair flanged ends for leak tight connections, high performance and stability in accurate flow control may be accurately administered for several sets of pipeline systems.
Send your Inquiry on RUFSupply Flange Gate Valve Now
- Video
- Why Choose RUFSupply
- Technical Data
Custom Manufacturing
Tailored solutions to match your exact specifications, from materials to pressure ratings.
Rigorous Testing
Every valve is tested for performance, durability, and safety before shipping.
Expert Technical Support
Our team of engineers is available to help you select the right valve for your application.
Competitive Pricing
Direct manufacturing ensures no intermediaries, saving you costs.
Global Standards Compliance
Our valves meet API, ASME, DIN, JIS, and GOST standards, ensuring reliability worldwide.
Request a Quote Today!
Need a reliable trunnion ball valve for your critical operations? RUFSupply is your trusted partner for durable and high-performance solutions.
Technical Data
What Is a Flanged Gate Valve?
A flanged gate valve is a type of shut-off valve used for on/off services in pipelines where the medium being conveyed is in liquid or gaseous state. It consists of a gate-like wedge that travels up and down to either open or shut off the flow and offers a commendably secure sealing when closed.
The difference of a flanged gate valve is that it has flanged ends that include a tightly sealed junction to the pipeline. These flanged ends facilitate easy fixing, dismantling and replacement of the joints and easy maintenance where high pressure or high temperature is involved. Feature rich and very strong flanged gate valve is widely used in oil and gas industry, water treatment, chemical processing etc where tight shut-off is necessary.
“This design of flanged ends ensures firm connections and great endurance making them suitable for use in pipeline systems under high pressures.”
Related Resource: Get more information on this on the Complete Valve Connection Guide that we wrote comparing flanged connections to other valve connection types, particularly threaded ones.
Why Choose RUF Supply’s Flanged Gate Valves?
When you decide to go for RUF Supply, what you are getting is quality and productivity. Here’s why our flanged gate valves are a cut above the rest:
Built to Last: Designed with good quality material in order to have the ability to endure extreme climate weather.
Reliable Sealing: Designed to provide a close and leakage-tight fit in all applications which put pressure on the pipe.
Versatile Sizes: Comes in different sizes and dimensions to suit most purposes and functions.
Affordable Pricing: Products that are affordable for the masses yet are of great quality.
Easy to Install and Replace: Easy installation and relatively low maintenance for easy wear and comfort for the train passengers.
“At RUF Supply, we have incorporated high quality with relative low costs on our Flanged Gate Valves to steer customers to that level that is considered optimal in the market.”
Key Features of Flanged Gate Valves
Here’s what makes RUF Supply’s flanged gate valves the ideal choice for your pipeline system:
1. Flanged ends are provided for high security attachment purposes.
Flanged ends also enhance the general attachment of the valve to the pipelines and give the valve a very strong hold thus minimizing leakage.
2. Mechanical Conception for Improved Seal
The wedge gate mechanism ensures that it can shut off well and aeration is minimized thus reducing leakages and can be relied upon in certain set critical applications.
3. Standardized Dimensions
Our valves come in 2-inch, 3-inch and 4-inch sizes, and the dimensions of our valves are standard with other systems making their application easy.
4. Reliability Under Stressing Conditions
Withstanding high temperature, pressure and corrosion environments, it presents long service life for users.
5. Non-complex nature for maintenance of the equipment and its replacement in case of any problem.
We use flanged gate valve designs that ensures that maintenance is easy, quick which means less downtime for your overall operations.
Understanding Flanged Gate Valve Dimensions
Selecting the right flanged gate valve requires careful consideration of its dimensions to ensure proper fit and functionality. At RUF Supply, we provide detailed specifications for each product, including:
Nominal Sizes: Common options include 2-inch, 3-inch, and 4-inch valves, with additional sizes available upon request.
Face-to-Face Dimensions: Adhering to industry API 600 or API 603 standards, these ensure your valve fits seamlessly into your pipeline.
Bolt Hole Patterns: Designed for precise alignment with flanged pipe connections, ensuring a secure installation.
“Valve dimensions are crucial selection criteria requiring the highest levels of compatibility, efficiency and durability with your pipeline systems.”
Helpful Tip: Additional information about standard valve sizes and dimensions can be found at our Valve Dimension Chart page.
How to Interpret Flanged Gate Valve Symbols
Reading the symbols on the engineering diagrams is important particularly in the process of installing and maintaining valves. A flanged gate valve symbol normally consists of the bar, which stands for the gate, positioned horizontally in a rectangle which depicts the valve body. There are symbolic indications that show that it is actually a shut-off device.
Confused about implementing this particular kind of engineering pictures? Now here is the team of professional to assist you about all valve symbols and technical information.
Competitive Pricing for Flanged Gate Valves
Unlike what most other product suppliers would undertake, at RUF Supply, we pride ourselves in selling quality products for less. Whether you’re buying a single valve or placing a bulk order, we’ve got cost-effective solutions for every buyer:
Affordable Options: Quality valves at reasonable cost.
Bulk Discounts: Special offers apply: prices reduce as the quantity of ordered product increases.
Transparent Pricing: No fine prints, but rather low costs that are provided to customers.
Apply for your flanged gate valve price today and find out how RUF Supply sets unprecedented value for money.
Request your flanged gate valve price today and see how RUF Supply can deliver value without compromise.
Why Professional Buyer Relies on RUF Supply
1. Industry Expertise
We have been in the business of the valve industry for years now making RUF Supply a go-to company for high performing products.
2. Unmatched Customer Service
The people working at Slabmaker are experienced and seeded with all the knowledge that a consumer will ever need about Slabs, from size selection, installation concerns, to maintenance.
3. We offer a fast shipping service with a no hassle return policy.
We are fully aware of the issue of time delivery. That’s why we have convenient delivery and easy to use return policy: Satisfaction is our guarantee, and speedy delivery is our promise.
“At RUF Supply we aim to be your number one supplier of all your valve requirements by providing you superior service at affordable prices.”
Interested in purchasing your Flanged Gate Valve?
Don’t wait—become the owner of the RUF Supply’s flanged gate valves that are key to your updated system. Select the range of products you are interested in; compare the sizes, prices and make your order. Press the button below to buy, or get your individual price quote.
Still have questions? For a detailed guide to the features and capabilities of the Flanged Gate Valve, read further in this article or reach out to our team for help.
or
A flanged gate valve is a commercially preferred choice for high-pressure and high-temperature systems as a reliable sealing that can be readily installed or removed. With flanged connections, many connections are secure and not so leakage and unsafe parts of a system of industrial applications such as pipelines, water treatment, and steam systems.
When measuring flanged gate valve size, pay most attentions on key factors such as face-to-face length, flange diameter, bolt circle pattern. Verify the valve dimensions match pipeline standards (ANSI or DIN) to ensure a minimum of compatibility, as well as secure attachment. Accurate measurements are guaranteed not to cause operational problems or leaks.
High-pressure flanged gate valves are built for high pressure performance without sacrifice. Made from robust materials such as stainless steel or carbon steel, these valves possess excellent sealing and are cattle inside harsh conditions. Sgt. Andrese are great for oil and gas pipelines, power provider equipment amongst chemical processing systems.
Industrial flanged gate valve is widely used in industries where tight shut-off is required, among them:
Oil & Gas: For controlling fluid flow in pipelines.
Water Treatment: Ensuring safe and efficient water distribution.
Chemical Processing: Handling corrosive or hazardous materials.
Power Generation: Working with steam and high-volatile media.
Regular maintenance of regular flanged gate valves should involve an inspection for wear or Portion of rust, cleaning to stop debris build−up, and/ or lubrication of shifting factors, including the stem. Make sure that the bolts on the type flanges tight, wherein the equipment would be leak. Early identification of problems, such as damaged seals, should be able to extend and meet the valve lifespan and save period.
Corrosive materials could be handled by flanged gate valves that are made from materials such as stainless steel or alloy steel. These materials are less reactive to chemicals and safeguard durability in vicinities as chemical plants, which have mainly impeded harmful elements.
If you are looking a flanged gate valve think about following questions.
Pressure and Temperature Range: Verify compatibility to system operating conditions.
Material: Choose material according to the type of fluid or gas it goes to handle (e.g. like carbon steel can be applied to water, like stainless steel for chemical substance).
Flange Standards: Make sure that the valve meets the requirements of pipeline like Ansi, Din, Iso.
Size: Select the suitable size to fit your pipeline size.
Leak-tight performance is provided by strong flanged connection and carefully designed sealing mechanism flanged gate valves. Proper installation with gaskets and bolts, presents a tight seal, the gate mechanism, secure shut-off, even in high-pressure environments.
The lifespan of a flanged gate valve relies on material quality, working situation, and also maintenance frequency. Suitable quality valves produced from very durable steel materials like stainless steel will deliver for decades with appropriate management, even with the most demanding industrial conditions.
Yes, flanged gate valves can productively be automated by electric, pneumatic and hydraulic actuators. Automation increases efficiency through remote operation, especially suitable for business which will have large-scale or dangerous systems such as for example oil refineries and power plants.
